12.3inch Automotive TFT LCD Display 1920x720 Wide Temperaturer LVDS Interface

Customized

Accepted

Sample Stock

Small amount stock

MOQ

500pcs

Lead Time

4-6 weeks

Payment

Bank transfer/Alibaba/Paypal

Shipping Port

HK/SZ

Prodcuts Details

SDT123QFI-06 12.3 inch Description:

Sunshine Display model SDT123QFI-06 serials are the standard 12.3 inch color TFT LCD, normally white with transmissive type TN panel, 1920*720 resolution, TBD driver IC, LVDS interface, 16.7M color depth, Anti-glare surface treatment. with RTP & CTP available, brightness 600 nits.

Key Features & Advantages

Outstanding optical performance with typical brightness up to 600 cd/m² and high contrast.
Industrial-grade reliability with a wide operating temperature range of -30~+85 and robust design for 24/7 continuous operation.
Flexible interface compatibility for easy integration with mainstream controllers and embedded platforms.
Long-lifetime LED backlight helps reduce total cost of ownership over the product lifecycle.

Application

For this 12.3 inch TFT LCD display, 1920*720 resolution, suitable for Industrial Equipment, Medical devices, Household appliances, Tester Equipment.

Why Choose Sunshine Display?

With more than 20 years of experience in LCD module manufacturing, Sunshine Display not only delivers high-quality products but also comprehensive technical support, including customization services, driver board integration guidance, and preferential pricing for volume orders. Every module undergoes a 72-hour aging test before shipment to ensure stable and reliable performance from day one.

Feature	Specification	Unit
Brand	Sunshine Display	-
Part Number	SDT123QFI-06	-
Size	12.3	inch
Resolution	1920*720	dots
LCD Type	IPS	-
Viewing Angle	ALL	o'clock
Luminance	600	cd/m2
LED Numbers	TBD	-
LCD Driver IC	TBD	-
Pin Number	50	-
Module Interface	LVDS	-
With/Without TP	Without TP	-
Touch Driver IC	-	-
Outline Dimension	308.3130.27.3	-
Active Area	292.032*109.512	mm
Operating Temperature	-30~+85	℃
Storage Temperature	-40~+90	℃
